| Imaging and optics | ||||
|---|---|---|---|---|
| Core technology | Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0 | |||
| Detector type | VOx, 7.5 to 14μm | |||
| Infrared resolution | 384×288@12μm | |||
| NETD | 15mK | |||
| Frame rate | 60Hz/9Hz | |||
| Focal length | 9mm | |||
| Field of view | 50°×37° | |||
| IFOV | 2.27mrad | |||
| Min. object distance | 0.5m | |||
| D:S | 441:1 | |||
| Focusing mode | Focus-free | |||
| Digital zoom | 2x / 4x / 8x | |||
