| Core technologie | Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0 | |||
| Detector type | VOx, 7.5 to 14μm | |||
| Infrarood resolution | 640×480@12μm | |||
| NETD | 15mK | |||
| Frame rate | 60Hz/9Hz | |||
| Brandpuntafstand | 9mm | |||
| Field of view | 50°×37° | |||
| IFOV (ruimtelijke resolutie) | 1.36mrad | |||
| Min. object afstand | 0.5m | |||
| D:S | 735:1 | |||
| Focus modus | Focus-free | |||
| Digitale zoom | 2x / 4x / 8x | |||
