The PR II series of multifunctional thermal imaging cameras provides firefighters with a clear and reliable image, precisely when conditions are at their most challenging. The cameras are certified as intrinsically safe and explosion-proof, making them suitable for demanding rescue and detection tasks.
Thanks to the combination of high resolution, a large display, multiple imaging modes, advanced temperature analysis and a high protection rating, the PR II series delivers reliable performance in extreme conditions. High temperatures, high humidity and thick smoke do not pose an insurmountable obstacle.
The PR II series helps firefighters to quickly gain an overview, accurately pinpoint the source of a fire and locate missing or trapped persons more swiftly. In this way, the camera supports more efficient operations and contributes to greater safety for both emergency responders and victims.
| Core technology | Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0 | |||
| Detector type | VOx, 7.5 to 14μm | |||
| Infrared resolution | 640×480@12μm | |||
| NETD | 15mK | |||
| Frame rate | 60Hz/9Hz | |||
| Focal length | 9mm | |||
| Field of view | 50°×37° | |||
| IFOV | 1.36mrad | |||
| Min. object distance | 0.5m | |||
| D:S | 735:1 | |||
| Focusing mode | Focus-free | |||
| Digital zoom | 2x / 4x / 8x | |||
